Notifier NFS2-3030 10-Loop Central Fire Alarm Control Panel (Expandable to a maximum of 20 Loops)
The NFS2-3030 fire panel is an intelligent addressable system with UL standards. Its modular design allows expansion up to 20 loops, managing 6360 addressable devices.
Detailed Information
- Certified for applications in seismic areas (earthquake-prone areas).
- Approved for marine applications.
- Addressable fire alarm control panel.
- Supports 1 to 10 SLC loops, meeting Style 4, 6, or 7 with a maximum of 159 addressable detectors and 159 addressable modules per loop.
- LCD display with 16x40 (640) characters and a QWERTY keyboard.
- Network expansion up to 103 panels with standard speed connection; 200 panels in high-speed connection mode.
- Capable of connecting with SWIFT wireless detectors.
- Storage capacity of up to 4,000 events and 1,000 alarm events.
- The controller remains operational even if the CPU fails.
- Provides 9 levels of sensitivity adjustment and 9 levels of pre-alarm.
- Detectors feature self-balancing adaptive mode to the environment.
- Complies with UL and FM standards.
Technical Specifications
- Input Voltage: 240 VAC, 50/60 Hz, 2.25 A
- DC Output Voltage:
+ Main 24 VDC: 5A
+ MAuxiliary 24 VDC: 5A
+ 5 VDC: 1.5A
- Battery Capacity Range: 7 AH – 200 AH
Central Fire Alarm Panel 1 Loop Notifier NFS-320E
The NFS-320E fire alarm control panel is part of the Onyx Notifier series of central fire alarm control panels. It is commonly used in small to medium-sized applications.
Notifier NFS2-640E 2-Loop Central Fire Alarm Control Panel
The NFS2-640E fire alarm control panel is part of the Onyx Notifier series of central fire alarm control panels. It is commonly used in small to medium-sized applications.
