Home/Product/Honeywell/Fire alarm/NOTIFIER ONYX

ACM-24AT Auxiliary Display Unit

Price:

Contact

The ACS Series ONSX provides LED and switch modules to annunciate status and control fire alarm panels, network controllers, or specific system output circuits.

Contact for consultation

Product information
Documents/Download

Detailed Information

- Speaker control mode for use with XPIQ and the following boards: NFS2-3030, NFS2-640, NFS-320 (C) and NFS-320SYS

- Programmable color LEDs

- On-board end-of-line resistors can be toggled on/off by setting a switch

- Alarm/Circuit On and Fault LEDs per point optional or denser. Alarm-only option

- Touch control switch option for remote control of system relays; or mute, reset, and evacuate.

- Programmable LEDs to display circuit or control relay indicator status as well as system status conditions.

- System fault indicator LED.

- Online/power indicator LED.

- Alarms and faults sound with flashing lights.

- Local audible alarm for both alarm and fault status with mute/confirmation button (programmable option).

- Easy labeling on the corresponding control panel.

Technical Specifications

- Can be powered by 24 VDC from the control panel or by a remote power source

- Provides 24 auxiliary display points (expandable to 96 points per unit)

- UL/FM compliant
